Double Disc Refiner

TSP series of double-disc refiner is the continuous beating equipment for raw and fine milling in pulping system of papermaking industry. It is also the high efficiency pulping equipment for pulp residue and waste paper. It has the advantage of high working efficiency and low power.

E-mail: sales@frdpapermachine.com
Тel:+86-13513810211 +86-15639109282
Chat Now
Send Inquiry
Specification
NO. DATA MODEL
UNIT TSP-Φ380 TSP-Φ450
1 DISC DIAMETER mm Φ380 Φ450
2 CAPACITY t/d 6-20 8-40
3 INLET CONSISTENCY % 2-5 2-5
4 INLET PRESSURE Mpa 0.1-0.3 0.1-0.3
5 INLET DIAMETER mm 2-Φ65 2-Φ70
6 OUTLET DIAMETER mm Φ70 Φ100
7 MOTOR KW Y250M-6/37KW Y315M-6/90KW
8 WEITHT Kg 1250 2000
9 OUTSIDE MEASURENMENT mm 2050×1360×650 2784×1360×855
